thick wires cutting and stripping machine from China manufacturer - Yueqing Linglong Automatic Equipment Co., Ltd.

thick wires cutting and stripping machine

Payment Terms:	T/T,L/C
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: LLBX-4

Production Capacity: 100 sets/ month

Delivery Date: 5 days

Means of Transport: Ocean,Land,Air

Packing: International standard pack...

Machine for stripping and cutting wires with size AWG # 8-28

Product information:

A fully-automatic machine is used for one-end or both-end full-stripping, semi-stripping or mid-stripping.

Mainly used for producing high-quantity or small-quantity but various type.

Digital controlling including key-board and LCD display is to make operation easily.

Large production range is applicable for wire #10AWG to # 28AWG.

It is designed to change the limiting of roller only for processing different wire materials. Designed with memory function for speeding up the production.

Product specification:
1) Overall size: 440×D400×H300 mm
2) Weight: 38 kg

3) Power supply: AC 220V/50HZ AC110V/60HZ
4) Power consumption: 400W, 5 stepping motors
5) Available stripping length: 0.2--30 mm
6) Available cutting length: 0.2-- 99999 mm
7) Cutting tolerance: ± (0.2+0.002*L) mm

8) Wire type: PVC, VSF, IV, KV, Teflon, Glass Wire
9) Wire size: AWG # 8-28
10) Processing speed: L=100mm A=B=3, 80pcs/min

11) 4-wheel driving

12) Machinery parts: High-quality motors and drivers, stainless steel outside case, Japan NSK bearing, Taiwan brand EG screw & fan. One set TGK inner hexagon spanner free of charge
